Zinc Plated Carriage Bolt
Carriage bolts are divided into large semi-circular head carriage bolts (corresponding to standard GB/T14 and DIN603) and small semi-circular head carriage bolts (corresponding to standard GB/T12-85) according to head size.
Submit

Still deciding? Get samples first! Get Sample

PRODUCT INTRODUCTION

Zinc Plated Carriage Bolt:



As a manufacturer located in China, we offer zinc plated carriage bolts perfect for merchants in countries outside of China. These bolts are designed to provide a secure fastening solution for various applications, including construction, woodworking, metalwork, and more. They are made from high-quality materials, which includes carbon steel or stainless steel, that meet industry standards to ensure their long-lasting durability.



Our zinc plated carriage bolts come in various sizes and lengths to cater to different requirements. This flexibility enables merchants to choose the right product for their application without having to compromise quality, strength, or performance. Customers can also find them in different thread sizes with different pitch levels to meet their needs. We offer customizable options to suit specific application needs as well.



Zinc plating is an added feature that provides resistance against rust and corrosion. This feature protects the bolts from potential damage caused by harsh weather conditions, making them suitable for outdoor applications. The zinc coating also adds an aesthetic value to the bolts, making them more attractive and appealing to the eye.



Our zinc plated carriage bolts have a square neck, which ensures a secure and snug fit. The square neck is designed to prevent rotation during installation or removal, ensuring a stable and secure fastening solution. The dome-shaped head of the bolt provides a smooth and sleek finish, making it less likely to catch on nearby objects, making them safer to use.



Our zinc plated carriage bolts are easy to install due to their pre-drilled holes, making it possible to screw them in easily. The installation process is further simplified since merchants do not require specialized tools or equipment. The bolts can be fastened using a simple wrench, making them suitable for both professional and DIY use.



Our zinc plated carriage bolts are strong and durable, making them reliable for long-term use. The zinc plating feature and overall quality of our products make them a cost-effective option for merchants. The quality of these products should not be confused with the low-cost options found in the market, which often compromise quality, leading to expensive maintenance and replacements costs in the future.



Conclusion:



The zinc plated carriage bolts that we offer are a reliable and durable option for merchants looking for secure fastening solutions. Our high-quality products, flexible sizing options, and resistance against rust and corrosion, make them suitable for various applications. Merchants can enjoy cost-effective solutions that do not compromise quality, leading to long-term savings. Our products are easy to install, safe to use, and come with pre-drilled holes that make installation effortless. At our company, we are committed to meeting our customers' needs by providing high-quality and reliable products that meet industry standards.



Carriage bolts are divided into large semi-circular head carriage bolts (corresponding to standard GB/T14 and DIN603) and small semi-circular head carriage bolts (corresponding to standard GB/T12-85) according to head size. Carriage bolt is consisting of head and screw (cylinder head with external thread), which needs matching with nut to fasten and connect two parts with through holes.

Usually, use environment of carriage bolts is special. Such as water industry, railway industry etc.. When olts  are used for external applications, galvanized carriage bolt will be a good choice. Zinc plated and hot-dip galvanized can make carriages bolts gain strong corrosion resistance. Of course due to the difference in plating process, the prices are also different. You can choose according to your own needs when purchasing.

Production Process of Carriage Bolts

01492866e2533982d2c3fb445048d53b

Specification of Zinc Plated Carriage Bolt

83f7bcea8ada77403aef9a08243e6269

d

M5

M6

M8

M10

M12

M16

M20

P

0.8

1

1.25

1.5

1.75

2

2.5

b

L≤125

16

18

22

26

30

38

46

125<L≤200

22

24

28

32

36

44

52

L>200

-

-

41

45

49

57

65

dk

max

13.55

16.55

20.65

24.65

30.65

38.8

46.8

min

12.45

15.45

19.35

23.35

29.35

37.2

45.2

ds

max

5

6

8

10

12

16

20

min

4.52

5.52

7.42

9.42

11.3

15.3

19.16

k1

max

4.1

4.6

5.6

6.6

8.75

12.9

15.9

min

2.9

3.4

4.4

5.4

7.25

11.1

14.1

k

max

3.3

3.88

4.88

5.38

6.95

8.95

11.05

min

2.7

3.12

4.12

4.62

6.05

8.05

9.95

r1

10.7

12.6

16

19.2

24.1

29.3

33.9

r2

max

0.5

0.5

0.5

0.5

1

1

1

r3

max

0.75

0.9

1.2

1.5

1.8

2.4

3

s

max

5.48

6.48

8.58

10.58

12.7

16.7

20.84

min

4.52

5.52

7.42

9.42

11.3

15.3

19.16

Common Grade and Coating

Standard

Material

Grade

Finish

Thread

DIN933 DIN931 ISO4014 ISO4017 ASME B 18.2.1

carbon steel

4.6 4.8 5.8 8.8 10.9 12.9 A2-70 A4-70

Plain

UNC

Zinc plated

Alloy steel

Yellow zinc plated

PTFE

Stainless steel

Black Oxide

UNF

Dacromet

Other

HDG

Other

Application Area of Zinc Plated Carriage Bolt

The carriage bolt is not widely used in our daily life because of its unique square neck design.Carriage bolt is very suitable for fixing wood to metal. Alternatively, square neck carriage bolts can be used to hold the two pieces of wood together. There are also special versions of carriage bolts that effectively fasten two separate metal parts together. In addition, they can be used in a variety of different industries including: water industry, railway industry, agriculture and mining.

0efdabf4e2f53ca3d300867875768eff



Why choose us?

  • If you're looking for a reliable supplier of Carriage Bolt products, we're your best choice.
  • We will provide you with excellent Zinc Plated Carriage Bolt and perfect pre-sales and after-sales service with all our heart.
  • Our Carriage Bolt products are manufactured with environmental responsibility in mind.
  • The important thing is that we never make false reputations, but are completely considerate of our customers and partners.
  • Our team is knowledgeable and experienced in all aspects of Carriage Bolt products and applications.
  • Relying on a strong brand, good service, super strong supply capacity and perfect market network, we provide customers with suitable Zinc Plated Carriage Bolt solutions.
  • Our Carriage Bolt products are easy to install and require minimal maintenance.
  • Our company has a group of experienced technical personnel and management personnel, continuous research and development of new products, and strive to innovate and improve.
  • Our factory is equipped with state-of-the-art machinery to ensure our Carriage Bolt products are top-quality.
  • We hope to build a learning-oriented enterprise, rely on scientific and technological progress, and accelerate the pace of development.
FAQ

Q1:Can you send samples?
A1:Of course, we can provide samples and courier services to customers around the world.
Q2:What if I have no import experience?
A2:We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.
Q3:How long is your lead time?
A3:If it is in stock, it is usually 5-10 days. Or, if there is no inventory, 15 days, depending on the quantity.
Q4:What are your terms of payment?
A4:30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100%.Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A.
Q5:How is your technical support?
A5:We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you call anytime.
